ARENA PolyElast PE DRY WATERPROOFING LUBRICATING ELASTIC MIXTURE

Скачать техническую
документацию PDF Области применения

The superficial lubricating waterproofing (elastic) on a cement basis of ARENA PolyElast PE is delivered in the form of dry mix which part special cements, mineral and polymeric substances with the expressed knitting properties and the melkofraktsionny quartz sand applied as a basis are. After mixing with the dosed amount of water, the dry mix ARENA PolyElast PE passes into a condition of the plastic sticky weight convenient for drawing to previously moistened surface of concrete structures with a brush or the pallet. Protective waterproofing coating is put in several layers with a total thickness not less than 2 millimeters, as a result forming a high-strength, crack-proof concrete membrane.

Предназначение Преимущества Технические характеристики Технология применения материала Строительные узлы Гарантии производителя

Предназначение:

DESCRIPTION: The dry waterproofing surface lubricating elastic mixture consists of a mixture of mineral and polymer, as well as quartz sand. After hardening it represents as a thin multilayer elastic (at least 2 layers) waterproof coat 2-5 mm applied on the surface of the insulated construction using a brush and a spatula. PURPOSE: The dry mix is designed for waterproofing concrete and stone structures by creating waterproof layers on the insulated surface.

Types of the processed surfaces:

concrete
reinforced concrete
stone
brick
metal
gypsum cardboard

Преимущества:

The thickness of 2 layers of the application not less than 2mm;
Effectively operates under direct water pressure;
Resistant to mechanical damage;
Has a high resistance to corrosive media;
Vapor permeability;
Economy;
Ease of use;
High adhesion and ability to perceive some deformations of the insulated surface (linear extensions, etc.);
The possibility of applying to the wet surface in a manual and mechanized way.

Технические характеристики:

№	Name of an index	Value*	Measurement methods*
1	Appearance	loose powder gray	TU 23.64.10-001-35155041-2017
2	W/F	0,15-0,16	TU 23.64.10-001-35155041-2017
3	Moisture by weight, not more than	0,3%	GOST 31376-2008
4	Bulk density	1250±100 kg/m3	GOST 8735, раздел 9
5	The greatest fineness of filler	0,63 mm	GOST 56703-2015
6	Content of grains of the greatest fineness, no more than	0,5%	GOST 56703-2015
7	Mobility	Pk1-Pk2	GOST 56703-2015
8	Start of setting, not less than	60 minutes	GOST 310.3, part 2
9	End of setting, not longer than	210 minutes	GOST 310.3, part 2
10	Density	2100±100 kg/m3	GOST 5802
11	Compressive strength after 1/28 days, more	15/45 MPa	GOST 5802
12	Bending strength after 7/28 days, more	8/10 MPa	GOST 310.4
13	Water resistance mark, more	W18	GOST 12730.5
14	Mark for frost resistance, more	F400	GOST 5802
15	Adhesion after 3/28 days, more	1,0/2,5 MPa	GOST 31356
16	Shrinkage at the 28 days, not less than	0,1%	TU 23.64.10-001-35155041-2017

* Tests were carried out according to STO 77956721-001-2017 "Descriptions and technology of use of waterproofing materials of the ARENA FORCE brand". All stated indicators of quality and the recommendation are right for ambient temperature 20oC and the relative air humidity of 90%. In other conditions technical characteristics of material can differ from specified.

Технология применения материала

PREPARATION OF FOUNDATION: Clean the insulated surface of the rests of plaster, paint and other impurities, preventing the adhesion of the waterproofing mixture to the foundation. Make a visual assessment of the site to be isolated and to identify water filtration sites. If there are active leaks, remove them with a dry mix of ARENA PlugMix PW “Hydraulic plug”. PREPARATION OF SOLVENT MIXTURE: Work should be carried out at a temperature of at least 5°C. Attention! When preparing the mortar mixture, only clean containers and water are used. To prepare such volume of a mortar mix which can be developed within 60 minutes from the moment of mixing with water. The optimum temperature of the mixing water is 20°C. Per 1 kg of the mixture requires 0.15-0.16 l. Optimal mixing is a low-speed drill. Mix for 3 minutes before forming a homogeneous, placer-free mass without lumps. Hold the technological pause for 3-5 minutes and mix the mixture again. Attention! The mortar mixture during the use should be regularly mixed to preserve the initial consistency. Re-adding water to the solution is not allowed. APPLICATION: Work should be done at a temperature of at least 5°C. The last coat should have a thickness of at least 2- 4 mm. Even if with a thickness of 2 mm can be applied with a spatula, it is necessary to apply at least 2 more layers to seal the pores and micro-cracks formed when the first layer is hardened. Depending on the volume of work, the mortar can be applied with a spatula or a brush. CONSUMPTION: The consumption of the mixture is 1.8 kg/m2 of concrete surface per 1 mm layer. CARE OF PROCESSED SURFACE: It is necessary to ensure that the treated surfaces remain moist for 3 days. For what you need to moisturize the surface 2-3 times a day.

Строительные узлы

Гарантии производителя

The manufacturer guarantees compliance of mix to requirements of specifications at observance by the consumer of storage precautions and indications of this instruction. A warranty period of container storage of the manufacturer – 18 months from the date of production on condition of undisturbed tightness of an original packing.

Safety:

It is necessary to avoid hit of mix in eyes and on skin. Mix contains cement and in interaction with water gives alkaline reaction therefore during the work it is necessary to use rubber gloves and goggles. At hit of mix in eyes it is necessary to wash them with water and to ask for the help the doctor. Storage conditions: Storage is allowed at any humidity and temperature from - 60oC to 50oC.
