ARENA RepairMaster R500 REPAIR COMPOSITION FOR CONCRETE HIGH-MARK

Скачать техническую
документацию PDF Области применения

The dry construction mix ARENA RepairMaster R500 is the effective repair structure of superficial action recommended for production of responsible construction and recovery work. The most important components of repair structure for ARENA RepairMaster R500 concrete are the quick-hardening portlandtsement, a complex of the special modifying additives and the polymeric reinforcing fibers intended for giving to the grabbed solution of special durability. As filler – a basic basis of the mix ARENA RepairMaster R500, clean quartz sand of different fractions is applied.

Предназначение Преимущества Технические характеристики Технология применения материала Строительные узлы Гарантии производителя

Предназначение:

The dry mix is intended for restoration of geometrical and operational parameters of a structure by their surface restoration. Can be applied by dry or wet tampering. DESCRIPTION: Dry construction mixture waterproof surface to stop active leaks mixture, consists of a mixture of alumina and Portland cement, quartz sand and a complex of additives accelerators for setting and hardening, as well as additives that prevent the mixture from blurring.

Преимущества:

High strength (especially in early hardening).
No shrinkage.
High adhesion to the substrate and water resistance.
The possibility of applying up to -10°С (ARENA Repair Master R500 Winter).

Технические характеристики:

strong>TECHNICAL CHARACTERISTICS

№	Name of an index	Value*	Measurement methods*
1	Technical characteristics of dry mix
1.1	Appearance	loose powder gray	TU 23.64.10-001-35155041-2017
1.2	Bulk density in standard condition	1400 ± 100 kg/m3	GOST 8735, part 9
2	Technical characteristics of solution mix
2.1	W/F	0,15-0,16	TU 23.64.10-001-35155041-2017
2.2	water retaining power	95-98 %	GOST 5802
2.3	Start of setting, min: start, not less than/ finish, not longer than	60/ 240	GOST 310.3, part 2
2.4	Density, kg/m3	2100 ± 100	GOST 5802
3	Technical characteristics of solution
3.1	Mobility	Pk1-Pk2	GOST 5802-86
3.2	Compressive strength after, MPa, more, after 1/7/28 days	22/50/70	GOST 5802
3.3	Flexural strength, MPa, more, after: 7 days/ 28 days	7,0/9,0	GOST 310.4
3.4	Water resistance mark, more	W14	GOST 12730.5
3.5	Shrinkage at the 28 days, % not more than	0,1	TU 23.64.10-001-35155041-2017
3.6	Adhesion, MPa, more, after 3 days/ after 28 days	0,9/3,0	GOST 31356
3.7	Mark for frost resistance, more	F400	GOST 5802

* Tests were carried out according to STO 77956721-001-2017 "Descriptions and technology of use of waterproofing materials of the ARENA FORCE brand". All stated indicators of quality and the recommendation are right for ambient temperature 20oC and the relative air humidity of 90%. In other conditions technical characteristics of material can differ from specified.

Технология применения материала

WORKING PROCESS:

Conduct a visual and instructional assessment of defective areas of concrete to calculate the required amount of materials. Clean the damaged areas from structurally weak concrete of other contaminants, preventing adhesion of the mortar to the surface of the repaired concrete. When bare reinforcing bars, remove the concrete around them no less than 15mm. If there are active leaks, remove them with a dry ARENA PlugMix PW "Hydraulic plug" mixture. Attention! Before applying ARENA RepairMaster R500, it is necessary to moisten the substrate with water to the maximum possible saturation.

PREPARATION OF SOLVENT MIXTURE:

Attention! For preparation of solution mix to use only clear water and a container. To prepare such volume of solution mix which can be developed within 60 minutes from the moment of mixing with water. The optimum temperature of the mixing water of 20°C per 1 kg of dry mixture requires 0,15-0,16 liters of water. It is best to mix with a low-speed drill. Mix for 3 minutes before forming a homogeneous plastic mass without lumps. Dissolve the mortar during use to maintain its original consistency. Re-adding water to the solution is not allowed. At temperatures close to 0°C, use a dry mixture of ARENA Repair Master R500 Winter.

APPLICATION:

Work should be done at a temperature of at least 5°C. Before applying the mortar mixture on the concrete surface of the repaired area should be abundantly moistened. Depending on the amount of work, the mortar can be applied with a trowel, a spatula manually or by wet-rolling. The optimum layer thickness of the applied material is 10 mm. When using a construction mixture ARENA Repair Master R500+ the maximum layer thickness of the applied material is 40 mm. The subsequent layers can be applied after 60-120 minutes, pre-moisturizing. The application of the repair mixture on large areas must be done on a masonry net. CARE OF PROCESSED SURFACE: It is necessary to ensure that the treated surfaces remain moist for 3 days. For what you need to moisturize the surface 2-3 times a day.

Строительные узлы

Гарантии производителя

The manufacturer guarantees compliance of mix to requirements of specifications at observance by the consumer of storage precautions and indications of this instruction. A warranty period of container storage of the manufacturer – 18 months from the date of production on condition of undisturbed tightness of an original packing.

Safety:

It is necessary to avoid hit of mix in eyes and on skin. Mix contains cement and in interaction with water gives alkaline reaction therefore during the work it is necessary to use rubber gloves and goggles. At hit of mix in eyes it is necessary to wash them with water and to ask for the help the doctor. Storage conditions: Storage is allowed at any humidity and temperature from - 60oC to 50oC.
